Description
The Solar Hybrid Inverter 12V 1kVA (IVCM1012) combines inverter, battery charger, and MPPT solar charge controller functions into one intelligent unit. Designed for 12V DC systems, it efficiently powers home or office loads up to 1 kW using solar, grid, or battery sources.
With pure sine wave output, it protects sensitive electronics while delivering stable and clean AC power. The integrated MPPT controller (900–1000W PV input) optimizes solar energy harvest and ensures faster battery charging.
It’s a plug-and-play hybrid inverter suitable for homes, offices, shops, and small solar installations.
⚙️ Key Features
-
Rated Power: 1 kVA / 1 kW
-
System Voltage: 12 V DC
-
Output Type: Pure Sine Wave
-
PV Input Range: 30–80 V DC
-
Max PV Power: 900–1000 W
-
MPPT Controller: Built-in 60A (approx.)
-
Switching: Automatic transfer between solar, battery, and grid
-
Battery Compatibility: Lead-acid, AGM, Gel, Lithium, LiFePO₄
-
Display: LCD screen for real-time monitoring
-
Operating Temperature: -10°C to +55°C
-
Communication: RS232/USB (varies by version)
-
Cooling: Smart temperature-controlled fan
-
Protection: Overload, short circuit, reverse polarity, overcharge, low voltage
Technical Specifications
| Parameter | Details |
|---|---|
| Model | IVCM1012 |
| Rated Power | 1 kVA / 1 kW |
| DC Input Voltage | 12 V |
| Output Voltage | 230 V AC ±10% |
| Output Frequency | 50 Hz ±0.5 Hz |
| Waveform | Pure sine wave |
| PV Input Voltage | 30–80 V DC |
| Max PV Input Power | 900 W |
| Max PV Current | 60 A |
| Battery Type | Lead-acid / Lithium / LiFePO₄ |
| Efficiency | ≥93% |
| Operating Temp. | -10°C to +55°C |
| Cooling | Intelligent fan |
| Weight | Approx. 6.5 kg |
| Color | White / Grey |
| Origin | Guangdong, China |
Packaging & Delivery
-
Selling Unit: 1× Inverter
-
Includes: User manual, connection cables, and warranty card
-
Dimensions: Compact and wall-mountable
-
Manufacturer: Felicity Solar
-
Supplier: Garblex Home Solutions
